The 6201 ZZ C3 is a deep groove ball bearing with metal shields on both sides (ZZ), designed to protect from larger particles while allowing low-friction rotation. It measures 12 x 32 x 10 mm and is widely used in household appliances, motors, and light industrial machinery. The C3 clearance supports higher speeds and improved durability.
Key Features
- Bearing Type: Deep Groove Ball Bearing
- Shield Type: ZZ (Double metal shields)
- Internal Clearance: C3 (increased radial clearance for thermal expansion and high-speed use)
- Material: Hardened chrome steel
- Lubrication: Factory pre-lubricated with long-life grease
- Cage: Pressed steel cage for durability and smooth operation
Applications
- Small electric motors
- Power tools and pumps
- Fans, blowers, and home appliances
- Automotive accessories
- Industrial machinery with compact shaft configurations
Equivalent Models
- SKF 6201-2Z/C3
- FAG 6201-ZZ-C3
- NTN 6201ZZC3
- KOYO 6201ZZ C3
| SD [mm] | D [mm] | B [mm] | R [mm] | CR1 [N] | COR1 [N] | FO | LG [rpm] | DAM1 [mm] | DA1 [mm] | DA2 [mm] | RA [mm] | MASS [kg] |
| 12 | 32 | 10 | 0.6 | 6800 | 3050 | 12.3 | 22000 | 16 | 17 | 28 | 0.6 | 0.037 |
